1537-717J
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Active Tape & Reel (TR) Ferrite fixed air core inductor 67MHz 600mOhm 5.6muH ±5%
PDF
/
Inventory: 5934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Technical
Packaging Tape & Reel (TR)
Series 1537-7
Size / Dimension 0.156Diax0.375L 3.96mmx9.53mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Current Rating (Amps) 490mA
Shielding Shielded
Current Rating 490mA
Inductance 5.6μH
Test Frequency 7.9MHz
DC Resistance (DCR) 600mOhm
Frequency - Self Resonant 67MHz
Q @ Freq 50 @ 7.9MHz
Inductance Frequency - Test 7.9MHz
Current - Saturation 165mA
Dimensions
Length 9.525mm
Compliance
RoHS Status Non-RoHS Compliant
