1537-36G
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~105C 45MHz 900mOhm Max 10muH
PDF
/
Inventory: 1888
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2010
Series 1537
Size / Dimension 0.156Diax0.375L 3.96mmx9.53mm
Tolerance ±2%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Construction Tubular
Current Rating 335mA
Lead Length 36.58mm
Inductance 10μH
Test Frequency 7.9MHz
DC Resistance (DCR) 900mOhm Max
Max DC Current 335mA
Frequency - Self Resonant 45MHz
Inductor Application RF INDUCTOR
Q @ Freq 55 @ 7.9MHz
Quality Factor-Min (at L-nom) 55
Q Factor 55
Dimensions
Diameter 3.96mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
