1537-04M
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active Contains Lead fixed air core inductor -55C~125C 360MHz 90mOhm Max 330nH
PDF
/
Inventory: 9383
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Weight 900.012311mg
Material - Core Phenolic
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2002
Series 1537
Size / Dimension 0.156Diax0.375L 3.96mmx9.53mm
Tolerance ±20%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Construction Tubular
Current Rating 1.58A
Lead Length 36.6mm
Inductance 330nH
Test Frequency 25MHz
DC Resistance (DCR) 90mOhm Max
Max DC Current 1.58A
Frequency - Self Resonant 360MHz
Inductor Application RF INDUCTOR
Q @ Freq 45 @ 25MHz
Quality Factor-Min (at L-nom) 45
Q Factor 45
Dimensions
Diameter 3.96mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
