1331-222K
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead fixed air core inductor -55C~105C 95MHz 1.1Ohm Max 2.2muH
PDF
/
Inventory: 9066
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.145 3.68mm
Height 3.68mm
Technical
Case/Size Code 3313
Q Factor 45
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 45
Q @ Freq 45 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 95MHz
Max DC Current 202mA
DC Resistance (DCR) 1.1Ohm Max
Test Frequency 7.9MHz
Inductance 2.2μH
Current Rating 202mA
Depth 3.18mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 0.313Lx0.115W 7.95mmx2.92mm
Series 1331
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
