1325-104K

API Delevan Inc.
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Molded Active 2013 fixed air core inductor -55C~105C 11.5MHz 15.5Ohm Max 100muH
PDF
/
Inventory: 1430
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Material - Core Iron

Technical

Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2013
Series 1325
Size / Dimension 0.133Diax0.260L 3.38mmx6.60mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Molded
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Current Rating (Amps) 61mA
Shielding Shielded
Current Rating 61mA
Inductance 100μH
Test Frequency 2.5MHz
DC Resistance (DCR) 15.5Ohm Max
Frequency - Self Resonant 11.5MHz
Q @ Freq 51 @ 2.5MHz
Inductance Frequency - Test 2.5MHz
Current - Saturation 61mA

Dimensions

Length 6.604mm

Compliance

RoHS Status Non-RoHS Compliant
