106-681K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead fixed air core inductor -55C~125C 160MHz 600mOhm Max 680nH
PDF
/
Buying Options
Total Price: USD $66.79
Unit Price: USD $66.787223
≥1 USD $66.787223
≥200 USD $26.649244
≥500 USD $25.759098
≥1000 USD $25.319277
Inventory: 8083
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Iron
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2002
Series 106
Size / Dimension 0.155Lx0.110W 3.94mmx2.79mm
Tolerance ±10%
Case/Size Code 1611
Q Factor 42
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 42
Q @ Freq 42 @ 25MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 160MHz
Max DC Current 410mA
DC Resistance (DCR) 600mOhm Max
Test Frequency 25MHz
Inductance 680nH
Current Rating 410mA
Construction Rectangular
Depth 2.79mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Terminal Finish Gold (Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e4
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.075 1.91mm
Height 1.91mm
