1025R-20K

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1025R Axial 0.095Diax0.250L 2.41mmx6.35mm 1muH
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.9184
≥1 USD $1.9184
≥10 USD $1.63416
≥100 USD $1.025323
≥500 USD $0.961242
≥1000 USD $0.897151
≥3000 USD $0.852298
Inventory: 1119
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter 2.41mm

Technical

Q Factor 25
Quality Factor-Min (at L-nom) 25
Q @ Freq 25 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 230MHz
Max DC Current 390mA
DC Resistance (DCR) 1Ohm Max
Test Frequency 25MHz
Inductance 1μH
Lead Length 38.1mm
Reference Standard MS75083
Current Rating 390mA
Construction Tubular
Number of Functions 1
Shielding NO
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.095Diax0.250L 2.41mmx6.35mm
Series 1025R
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Weight 300mg
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
