SH150S-0.46-78
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Toroidal Active Tape & Reel (TR) fixed air core inductor -40C~125C 10kHz 800mOhm 78muH
PDF
/
Inventory: 938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10.9982mm
Length 11.2014mm
Height Seated (Max) 0.301 7.65mm
Height 7.3914mm
Technical
Inductance Frequency - Test 10kHz
DC Resistance (DCR) 800mOhm
Test Frequency 10kHz
Inductance 78μH
Current Rating 460mA
Shielding Unshielded
Current Rating (Amps) 460mA
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Toroidal
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Tolerance ±20%
Size / Dimension 0.441Lx0.433W 11.20mmx11.00mm
Series SH150
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
