AFBR-5803AQZ
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Optoelectronics / Fiber Optics - Transceiver Modules
Description
TXRX ETHERNET 3.3V SC 1X9
PDF
/
Buying Options
Total Price: USD $64.44
Unit Price: USD $64.43565
≥1 USD $64.43565
≥10 USD $52.87035
≥100 USD $51.21735
≥500 USD $49.5653
≥1000 USD $47.91325
≥3000 USD $42.9571
Inventory: 1604
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case SIP
Number of Pins 9
Technical
Packaging Box
Published 2008
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type SC
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Ethernet
HTS Code 8517.62.00.50
Voltage - Supply 3.3V 5V
Supply Voltage 3.3V
Max Output Current 50mA
Operating Supply Voltage 5V
Output Current 50mA
Data Rate 100Mbps
Rise Time 3ns
Fall Time (Typ) 3 ns
Wavelength 1300nm
Fiber Type 50/125, 62.5/125, MMF
Built-in Feature AMPLIFIER
Operating Wavelength-Nom 1308 nm
Emitter/Detector Type LED, PIN PHOTODIODE
Optical Power Output-Nom 0.022mW
Communication Standard ATM, OC-3C, SONET
Dimensions
Height 10.35mm
Length 39.12mm
Width 25.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
