6100-W
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Fiber Optic Connectors
Description
3M 6100-W Fibre Optic Connector, ST, Singlemode, Multimode, 125m, Metal Body, 6100 ST Series
PDF
/
Inventory: 2287
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Material Zinc
Housing Material Engineered Resin
Weight 907.18474g
Body Material Engineered Resin
Ferrule material Zirconia
Technical
Operating Temperature -40°C~85°C
Published 1998
Feature Dust Cap, Hot Melt, Strain Relief
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug
Max Operating Temperature 60°C
Min Operating Temperature -40°C
Color White
Gender Male
Fastening Type Bayonet Lock
Orientation Straight
Housing Color Silver
Connector Style ST
Mating Cycles 500
Insulation Diameter 2.9 mm
Wire/Cable Diameter 900 μm
Cable Diameter 0.9mm
Simplex/Duplex Simplex
Mode Multimode
Fiber Cladding Diameter 125μm
Boot Color White
Attenuation - Typ -0.2dB
Reflection -25dB
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
