54548-1870 image
Favorite
54548-1870 image
Favorite

54548-1870

Molex
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description ZIF FFC Connector
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.277061
≥1 USD $1.277061
≥10 USD $1.20477
≥100 USD $1.136571
≥500 USD $1.072242
≥1000 USD $1.011549
Inventory: 1170
Minimum: 1
-
+

Technical Details

Technical

PCB Contact Pattern RECTANGULAR
Body Breadth 0.047 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Contact Resistance 40mOhm
Insulation Resistance 50MOhm
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Straight
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Number of Contacts 18
Lead Pitch 500μm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Current Rating 500mA
Orientation Right Angle
Pitch 500μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 50V
Subcategory Headers and Edge Type Connectors
Additional Feature ZIF
Number of Rows 1
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free

Physical

Actuator Material Polyphenylene
Housing Material Polymer
Mount Surface Mount
Contact Plating Tin
Contact Material Bronze
