87438-1343
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 13 CKT 1.5mm HDR. Rt.-Angle SMT
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.071829
≥1 USD $1.071829
≥10 USD $1.011168
≥100 USD $0.953936
≥500 USD $0.899932
≥1000 USD $0.848995
Inventory: 907
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 100u inch
Technical
Insulator Color BEIGE
Contact Pattern RECTANGULAR
Durability 10 Cycles
Dielectric Withstanding Voltage 700VAC V
Polarization Key POLARIZED HOUSING
Termination Type SURFACE MOUNT
Body/Shell Style PLUG
Mating Contact Pitch 0.059 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 40mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2.5A
Body Depth 0.305 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.175 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Body Length or Diameter 0.819 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code compliant
Terminal Pitch 1.5mm
Total Number of Contacts 13
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Connector Type BOARD CONNECTOR
Part Status Active
Pbfree Code icon-pbfree yes
Published 2004
Physical
Mounting Style RIGHT ANGLE
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED NYLON
Mounting Type BOARD
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 11 Weeks
