52559-1470
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors 0.5 FPC ZIF Hsg Assy SMT 14Ckt EmbsTpPkg
PDF
/
Inventory: 9058
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Nylon
Actuator Material Polyphenylene
Technical
Packaging Tape and Reel
Published 2013
JESD-609 Code e6
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Receptacle
Voltage - Rated 50V
Additional Feature ROHS, ELV COMPL & EMBOSSED PKG
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1mm
Depth 3mm
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 500μm
Number of Contacts 14
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Housing Color Natural
Rated Current (Signal) 0.5A
Contact Style SINGLE PRONG
Contact Resistance 20mOhm
Insulation Resistance 50000000Ohm
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Straight
PCB Contact Row Spacing 2.794 mm
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Insulator Color BEIGE
Dimensions
Length 12.7mm
Plating Thickness 39μin
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
