5035660902
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.768047
≥1 USD $0.768047
≥200 USD $0.307219
≥500 USD $0.296715
≥1000 USD $0.291464
Inventory: 3409
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series Easy-On 503566
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 9
Voltage - Rated 50V
Current Rating (Amps) 0.2A
Pitch 0.012 0.30mm
Contact Finish Gold
Housing Color White
Mating Cycles 10
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tabbed
Locking Feature Flip Lock
Actuator Color Black
Dimensions
Height Above Board 0.037 0.95mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0, UL94 HB
RoHS Status ROHS3 Compliant
