0781193220
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 6463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.161 4.10mm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Cable End Type Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Mating Cycles 10
Housing Color Black
Contact Finish Gold
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 32
Connector Type FFC/FPC CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Easy-On 78119
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
