0520451745
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
52045 ROHS3Compliant GENERAL PURPOSE FEMALE FFC, FPC (Connector/Contact Type) Connector -40C~85C 1A 200V 35.4muin 0.90mum
PDF
/
Inventory: 9835
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.315 8.00mm
Contact Finish Thickness 35.4μin 0.90μm
Technical
Cable End Type Straight
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Body/Shell Style RECEPTACLE
Housing Color Gray
Contact Gender FEMALE
Contact Finish Tin
Total Number of Contacts 17
Pitch 0.049 1.25mm
Current Rating (Amps) 1A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.51
Voltage - Rated 200V
Number of Rows 1
Number of Positions 17
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Kinked Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 52045
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Housing Material Polybutylene Terephthalate (PBT), Polyester
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 10 Weeks
