RM6S/I-3C94
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 1777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 6
Material 3C94
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Ungapped
Effective Area (Ae) mm2 37
Effective Length (le) mm 29.2
Effective Magnetic Volume (Ve) mm3 1090
Core Factor (ΣI/A) mm1 0.784
Minimum Core Cross Section (Amin) mm2 31.2
Effective Permeability (μe) 1360
Dimensions
Height 12.40mm
Length 17.90mm
Width 8.20mm
Compliance
RoHS Status ROHS3 Compliant
