RM4/I-3C96
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 1787
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 4
Material 3C96
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Ungapped
Effective Area (Ae) mm2 13.8
Effective Length (le) mm 23.3
Effective Magnetic Volume (Ve) mm3 322
Core Factor (ΣI/A) mm1 1.69
Minimum Core Cross Section (Amin) mm2 11.5
Dimensions
Height 10.40mm
Length 11.00mm
Width 9.80mm
Compliance
RoHS Status ROHS3 Compliant
