ER11/2.5/6-3F36-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PLANAR ER CORES 2PC SET
PDF
/
Inventory: 7241
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2.45mm
Length 11.00mm
Height 6.00mm
Technical
Minimum Core Cross Section (Amin) mm2 10.3
Core Factor (ΣI/A) mm1 1.23
Effective Magnetic Volume (Ve) mm3 174
Effective Length (le) mm 14.7
Effective Area (Ae) mm2 11.9
Gap Ungapped
Core Type ER
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3F36
Supplier Device Package ER 11 x 2.5 x 6
Supply Chain
Factory Lead Time 7 Weeks
