TIBPAL20L8-25CFN

Texas Instruments
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description IC PLD 25NS 28PLCC
PDF
/
Inventory: 1976
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 11.5062mm
Length 11.5062mm
Height Seated (Max) 4.57mm

Technical

Number of Product Terms 64
Number of Dedicated Inputs 14
Output Function COMBINATORIAL
Organization 14 DEDICATED INPUTS, 6 I/O
Turn On Delay Time 25 ns
Propagation Delay 25 ns
Nominal Supply Current 105mA
Number of I/O 6
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type PAL
Temperature Grade COMMERCIAL EXTENDED
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 8
Pin Count 28
Base Part Number TIBPAL20L8
Frequency 50MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 220
Terminal Form J BEND
Terminal Position QUAD
Technology TTL
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Series IMPACT-X? PAL?
Packaging Tube

Physical

Weight 1.182714g
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
