ICS843801AGI-24LFT image
Favorite
ICS843801AGI-24LFT image
Favorite
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description Crystal TSSOP CLOCK GENERATOR OTHER ALSO OPERATES AT 3.3V SUPPLY clock generator ic 2.625V 405MHz 4.4mm -40C
PDF
/
Inventory: 6719
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case TSSOP

Technical

Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES AT 3.3V SUPPLY
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 2.625V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.375V
Number of Circuits 1
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, OTHER
Frequency (Max) 405MHz
Input Crystal
Primary Clock/Crystal Frequency-Nom 25.3125MHz
PLL Yes

Dimensions

Length 4.4mm
Width 3mm

Compliance

RoHS Status RoHS Compliant
