TIBPAL16R8-25CN
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
TTL DUAL POWER-UP RESET COMMERCIAL EXTENDED Programmable Logic Device (PLD) IC 75C 4.75V 30MHz 4.57mm
PDF
/
Buying Options
Total Price: USD $8.86
Unit Price: USD $8.8597
≥1 USD $8.8597
≥10 USD $7.27035
≥100 USD $7.04235
≥500 USD $6.8153
≥1000 USD $6.58825
Inventory: 147
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 6.35mm
Length 24.33mm
Height 4.57mm
Technical
Number of Product Terms 64
Number of Dedicated Inputs 8
Output Function REGISTERED
Access Time 25 ns
Turn On Delay Time 25 ns
Propagation Delay 25 ns
Max Supply Current 100mA
Nominal Supply Current 100mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Number of Circuits 8
Programmable Type PAL
Temperature Grade COMMERCIAL EXTENDED
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 8
Pin Count 20
Base Part Number TIBPAL16R8
Frequency 30MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Technology TTL
Subcategory Programmable Logic Devices
Additional Feature POWER-UP RESET
Min Operating Temperature 0°C
Max Operating Temperature 75°C
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series IMPACT-X? PAL?
Packaging Tube
Physical
Number of Pins 20
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
