ATF22V10CQ-15PC
RoHS
/
Package 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
1997 Non-RoHS Compliant Contains Lead Obsolete Programmable Logic Device (PLD) IC 70C 5V 83.3MHz 15ns
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 17
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Number of Macro Cells 10
Max Frequency 83.3MHz
Access Time 15 ns
Propagation Delay 15 ns
Speed 15ns
Voltage - Input 5V
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type EE PLD
Base Part Number ATF22V10C
Frequency 83.3MHz
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 22V10
Published 1997
Packaging Tube
Physical
Supplier Device Package 24-PDIP
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
