ATF16V8B-10JU
RoHS
RoHS compliant
RoHS compliantPackage 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
IC PLD 8MC 10NS 20PLCC
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.2408
≥100 USD $1.21
Inventory: 518
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Number of Pins 20
Weight 722.005655mg
Technical
Packaging Tube
Published 1997
Series 16V8
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 83MHz
Base Part Number ATF16V8B
Number of Outputs 8
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Programmable Type EE PLD
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Operating Supply Current 55mA
Number of I/O 8
Nominal Supply Current 55mA
Memory Type FLASH
Max Supply Current 95mA
Propagation Delay 10 ns
Turn On Delay Time 10 ns
Access Time 20 ns
Architecture PAL-TYPE
Number of Gates 150
Output Function MACROCELL
Number of Macro Cells 8
Number of Dedicated Inputs 8
Ambient Temperature Range High 85°C
Number of Product Terms 64
Dimensions
Height 4.572mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
