TMS320F2808ZGMA
RoHS
RoHS compliant
RoHS compliantPackage 100-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 32-Bit Digital Sig Controller w/Flash
PDF
/
Buying Options
Total Price: USD $322.17
Unit Price: USD $322.17445
≥1 USD $322.17445
Inventory: 192
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 10mm
Length 10mm
Height 1.4mm
Technical
Internal Bus Architecture MULTIPLE
Barrel Shifter NO
Number of External Interrupts 3
Number of Timers 10
Number of UART Channels 2
Integrated Cache NO
Number of Programmable I/O 35
Number of A/D Converters 16
Low Power Mode YES
Boundary Scan YES
Core Architecture TMS320
PWM Channels 12
Data Bus Width 32b
Data Converter A/D 16x12b
Bit Size 32
Connectivity CANbus, I2C, SCI, SPI, UART/USART
Program Memory Size 128KB 64K x 16
Core Size 32-Bit
Program Memory Type FLASH
Peripherals POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 1.71V~1.89V
RAM Size 18K x 16
Oscillator Type Internal
Memory Size 128kB
Interface CAN, I2C, SCI, SPI, UART, USART
Power Supplies 1.83.3V
Supply Voltage-Max (Vsup) 1.89V
Operating Supply Voltage 1.8V
Pin Count 100
Base Part Number 320F2808
Frequency 100MHz
Terminal Pitch 0.8mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Digital Signal Processors
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series Automotive, AEC-Q100, C2000? C28x Fixed-Point
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 100
Package / Case 100-LFBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
