TMS320F280260PTS
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Contains Lead ROHS3Compliant GULL WING QUAD Microcontroller -40C~125C TA 90mA 50MHz 7mm
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.557946
≥1 USD $3.557946
≥10 USD $3.356555
≥100 USD $3.166559
≥500 USD $2.98732
≥1000 USD $2.818225
Inventory: 1307
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series C2000? C28x Piccolo?
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 48
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Number of UART Channels 1
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x12b
Bit Size 32
Supply Current-Max 90mA
Connectivity I2C, SCI, SPI, UART/USART
Program Memory Size 16KB 8K x 16
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.71V~1.995V
RAM Size 3K x 16
Number of I/O 22
Oscillator Type Internal
Memory Size 16kB
Interface I2C, SCI, SPI, UART, USART
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number 320F280260
Frequency 50MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7mm
