MSP430G2332IPW14
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU Mixed Signal Micro controller
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.0768
≥1 USD $2.0768
≥10 USD $1.8656
≥100 USD $1.499326
≥500 USD $1.407868
≥1000 USD $1.231868
≥3000 USD $1.020694
Inventory: 86
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 14
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Number of GPIO 16
RAM (bytes) 256
Number of UART Channels 0
Integrated Cache NO
Format FIXED-POINT
Number of A/D Converters 8
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 1
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 16
Connectivity I2C, SPI, USI
Program Memory Size 4KB 4K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 256 x 8
Number of I/O 10
Oscillator Type Internal
Memory Size 4kB
Interface I2C, SPI
Power Supplies 2/3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 14
Frequency 16MHz
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430G2xx
Packaging Tube
Operating Temperature -40°C~85°C TA
