MSP430F2272TRHAT
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 40VQFN
PDF
/
Buying Options
Total Price: USD $6.16
Unit Price: USD $6.16
≥1 USD $6.16
≥10 USD $5.56072
≥100 USD $5.302176
≥500 USD $4.603808
Inventory: 1278
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of PWM Channels 3
Number of Timers 6
Number of Serial I/Os 2
RAM (words) 1
Integrated Cache NO
Format FIXED-POINT
Number of A/D Converters 12
Low Power Mode YES
Boundary Scan YES
DAC Channels NO
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x10b
Bit Size 16
Supply Current-Max 0.55mA
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 32KB 32K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 1K x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 32kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Pin Count 40
Frequency 16MHz
Terminal Pitch 0.5mm
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology BIPOLAR
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430F2xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Weight 103.986051mg
Number of Pins 40
Surface Mount YES
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Alternative Model
