LM3S9L97-IQC80-C1
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM Microcontrollers - MCU Stellaris MCU
PDF
/
Inventory: 3192
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series Stellaris? ARM? Cortex?-M3S 9000
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Frequency 80MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LM3S9L97
Pin Count 100
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 1.32V
Interface CAN, Ethernet, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 128kB
Oscillator Type Internal
Number of I/O 60
RAM Size 48K x 8
Voltage - Supply (Vcc/Vdd) 1.235V~1.365V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 128K x 8
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 16x10b
Has ADC YES
DMA Channels YES
Data Bus Width 32b
DAC Channels NO
Number of Timers/Counters 4
ROM (words) 131072
Core Architecture ARM
Number of PWM Channels 6
Dimensions
Length 16mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
