LM3S6C11-IQC80-A2T
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 100LQFP
PDF
/
Inventory: 7447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Stellaris? ARM? Cortex?-M3S 6000
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 80MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LM3S6C11
Pin Count 100
Qualification Status Not Qualified
Supply Voltage-Min (Vsup) 3V
Interface Ethernet, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 512kB
Oscillator Type Internal
Number of I/O 46
RAM Size 64K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity Ethernet, I2C, IrDA, LINbus, Microwire, SPI, SSI, UART/USART
Bit Size 32
Has ADC YES
DMA Channels YES
PWM Channels YES
Number of Timers/Counters 4
Core Architecture ARM
Number of UART Channels 3
Number of ADC Channels 0
Dimensions
Height Seated (Max) 1.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
