MAX1589AETT180+

Maxim Integrated
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Positive NO LEAD Not Qualified BICMOS voltage regulator linear 85C 1.951W 0.5A 2.9mm
PDF
/
Inventory: 8710
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Number of Pins 6

Technical

JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology BICMOS
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Terminal Pitch 0.95mm
Pin Count 6
Number of Outputs 1
Qualification Status Not Qualified
Output Type Fixed
Polarity Positive
Power Dissipation-Max 1.951W
Quiescent Current 140μA
Accuracy 0.5 %
Voltage - Output 1.8V
Output Voltage 1 1.8V
Min Input Voltage 1.62V
Max Input Voltage 3.6V
Dropout Voltage1-Nom 0.175V
Output Current1-Max 0.5A
Input Voltage Absolute-Max 4V
Load Regulation-Max(%) 0.009%

Dimensions

Height Seated (Max) 0.8mm
Length 2.9mm
Width 2.9mm

Compliance

RoHS Status RoHS Compliant
