STM32L152V8T6A
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
STMICROELECTRONICS STM32L152V8T6A 32 Bit Microcontroller, Ultra Low Power, ARM Cortex-M3, 32 MHz, 64 KB, 32 KB, 100 Pins, LQFP
PDF
/
Buying Options
Total Price: USD $6.27
Unit Price: USD $6.2744
≥1 USD $6.2744
≥10 USD $5.66984
≥100 USD $5.406016
≥500 USD $4.694017
≥1000 USD $4.48301
≥3000 USD $4.087459
Inventory: 248
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32L1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Max Power Dissipation 435mW
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM32L152
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size 64kB
Oscillator Type Internal
Number of I/O 83
RAM Size 32K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 64K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
Number of Timers/Counters 8
Core Architecture ARM
EEPROM Size 4K x 8
Number of ADC Channels 14
Number of I2C Channels 2
Number of USB Channels 1
Dimensions
Height 1.45mm
Length 14.2mm
Width 14.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
