SPC5517EAMLU66
RoHS
RoHS compliant
RoHS compliantPackage 176-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 1.5MB FLASH 125C
PDF
/
Buying Options
Total Price: USD $894.93
Unit Price: USD $894.92755
≥1 USD $894.92755
Inventory: 123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 176-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Published 2004
Series MPC55xx Qorivva
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 176
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn)
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SPC5517
JESD-30 Code S-PQFP-G176
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 137
Speed 66MHz
RAM Size 80K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.25V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor e200z0, e200z1
Peripherals DMA, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 32-Bit Dual-Core
Program Memory Size 1.5MB 1.5M x 8
Connectivity CANbus, EBI/EMI, I2C, SCI, SPI
Bit Size 32
Data Converter A/D 40x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Address Bus Width 32
ROM (words) 196608
Screening Level AEC-Q100
External Data Bus Width 32
Dimensions
Height Seated (Max) 1.6mm
Length 24mm
Width 24mm
Compliance
RoHS Status ROHS3 Compliant
