S912XEP100W1MALR
RoHS
RoHS compliant
RoHS compliantPackage 112-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU BL Auto Micro Processors
PDF
/
Buying Options
Total Price: USD $68.06
Unit Price: USD $68.0599
≥1 USD $68.0599
≥10 USD $65.93285
≥100 USD $63.80675
≥500 USD $61.6797
≥1000 USD $55.29855
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 112-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 1996
Series HCS12X
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 112
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 1.8V
Terminal Pitch 0.65mm
JESD-30 Code S-PQFP-G112
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 1.98V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 1.72V
Oscillator Type External
Number of I/O 91
Speed 50MHz
RAM Size 64K x 8
Voltage - Supply (Vcc/Vdd) 1.72V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Peripherals LVD, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, I2C, IrDA, SCI, SPI
Supply Current-Max 100mA
Bit Size 16
Data Converter A/D 16x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
ROM (words) 1048576
EEPROM Size 4K x 8
CPU Family CPU12
Screening Level AEC-Q100
RAM (bytes) 65536
Dimensions
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
