S9S12XF384J2MLMR
RoHS
/
Package LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 3783
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case LQFP
Surface Mount YES
Technical
Packaging Tape & Reel
Moisture Sensitivity Level (MSL) 3
Number of Terminations 112
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 1.8V
Terminal Pitch 0.65mm
JESD-30 Code S-PQFP-G112
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 1.98V
Temperature Grade AUTOMOTIVE
Interface SCI, SPI
Memory Size 384kB
Number of I/O 91
RAM Size 24kB
Memory Type FLASH
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Bit Size 16
Frequency (Max) 40MHz
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
Halogen Free Halogen Free
Number of Timers/Counters 16
CPU Family CPU12
Screening Level AEC-Q100
Number of Programmable I/O 110
RAM (bytes) 24576
Dimensions
Length 20mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
