PIC18LF65K80T-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 32KB FL 4KBRM 16MIPS 12bit ADC CTMU XLP
PDF
/
Inventory: 5618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series PIC? XLP? 18K
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 64MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18LF65K80
Pin Count 64
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 3V
Interface CAN, I2C, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 54
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity ECANbus, I2C, LINbus, SPI, UART/USART
Supply Current-Max 11mA
Bit Size 8
Data Converter A/D 11x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 5
ROM (words) 32768
EEPROM Size 1K x 8
CPU Family PIC
Dimensions
Length 9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
