PIC16LF1526T-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 14K FL 768B RAM 10-bit ADC 1.8-3.6V
PDF
/
Inventory: 2505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 1mm
Technical
Number of Programmable I/O 53
CPU Family PIC
On Chip Program ROM Width 14
Number of Timers/Counters 9
DAC Channels YES
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 30x10b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 14KB 8K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 768 x 8
Number of I/O 54
Oscillator Type Internal
Memory Size 14kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 64
Base Part Number PIC16LF1526
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT 1.8 V MINIMUM SUPPLY AT 16 MHZ
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
