UCC38C43DGKG4
RoHS
/
Package VSSOP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
Flyback Boost Rail/Tube e4 ALSO OPERATES IN CURRENT MODE DC to DC switching controller 20ns 200mA 25.996513mg 15V
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.799985
≥1 USD $1.799985
≥10 USD $1.698103
≥100 USD $1.601985
≥500 USD $1.511305
≥1000 USD $1.425758
Inventory: 4047
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case VSSOP
Number of Pins 8
Weight 25.996513mg
Technical
Packaging Rail/Tube
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 2
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature ALSO OPERATES IN CURRENT MODE
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Frequency 1MHz
Pin Count 8
Number of Outputs 1
Input Voltage-Nom 15V
Temperature Grade COMMERCIAL
Max Supply Voltage 18V
Analog IC - Other Type SWITCHING CONTROLLER
Current - Output 200mA
Voltage - Output 18V
Topology Flyback, Boost
Control Mode VOLTAGE-MODE
Frequency - Switching 1MHz
Control Technique PULSE WIDTH MODULATION
Rise Time 25ns
Fall Time (Typ) 20 ns
Nominal Input Voltage 18V
Switcher Configuration SINGLE
Max Duty Cycle 100 %
Duty Cycle (Max) 100 %
Dimensions
Height 970μm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
