PIC16F722A-I/MV
RoHS
RoHS compliant
RoHS compliantPackage 28-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 3.5KB Flash 3.3V/5V 28-Pin UQFN EP
PDF
/
Inventory: 9154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height 500μm
Technical
Number of USB Channels 1
Number of PWM Channels 2
Number of ADC Channels 11
CPU Family PIC
Number of Timers/Counters 3
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 11x8b
Bit Size 8
Connectivity I2C, SPI, UART/USART
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 128 x 8
Number of I/O 25
Oscillator Type Internal
Memory Size 3.5kB
Interface I2C, SPI, UART, USART
Supply Voltage-Max (Vsup) 5.5V
Pin Count 28
Base Part Number PIC16F722A
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? XLP? 16F
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
