PIC16F506-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB FLASH 14SOIC
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.406261
≥1 USD $1.406261
≥10 USD $1.373558
≥100 USD $1.352627
Inventory: 32
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Technical
Number of Programmable I/O 12
CPU Family PIC
On Chip Program ROM Width 12
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 8 μs
Data Converter A/D 4x8b
Bit Size 8
Supply Current-Max 2mA
Program Memory Size 1.5KB 1K x 12
Core Size 8-Bit
Program Memory Type FLASH
Peripherals POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 67 x 8
Number of I/O 11
Oscillator Type Internal
Memory Size 1.5kB
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 2/5.5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 14
Base Part Number PIC16F506
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 700mW
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT MINIMUM 2V AT 4MHZ
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16F
Published 2007
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
