PIC16F1823-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 3.5KB 128B RAM 32MHz Int. Osc 12 I/0
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $1.1264
≥100 USD $1.0384
Inventory: 35951
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height 1.5mm
Technical
Number of I2C Channels 1
Number of ADC Channels 8
CPU Family PIC
EEPROM Size 256 x 8
Address Bus Width 8b
Number of Timers/Counters 3
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 128 x 8
Nominal Supply Current 145μA
Number of I/O 12
Oscillator Type Internal
Memory Size 3.5kB
Interface I2C, LIN, SPI, UART, USART
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 14
Base Part Number PIC16F1823
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Supply Voltage 2.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 9 Weeks
