ST72F561J9TAXS

STMicroelectronics
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 7344
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Surface Mount YES

Technical

Published 2011
Number of Terminations 44
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 44
JESD-30 Code S-PQFP-G44
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.5V
Number of I/O 34
Speed 8 MHz
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Clock Frequency 16MHz
Supply Current-Max 15mA
Bit Size 8
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
ROM (words) 61440
On Chip Program ROM Width 8
CPU Family ST72
RAM (bytes) 2048
ROM Programmability FLASH

Dimensions

Height Seated (Max) 1.6mm
Length 10mm
Width 10mm

Compliance

RoHS Status Non-RoHS Compliant
