PIC16F1507T-I/GZ
RoHS
RoHS compliant
RoHS compliantPackage 20-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-Bit PIC16 PIC RISC 3.5KB Flash 2.5V/3.3V/5V 20-Pin UQFN EP T/R
PDF
/
Inventory: 3129
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-UFQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series PIC? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC16F1507
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 17
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Supply Current-Max 1.8mA
Bit Size 8
Data Converter A/D 12x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
On Chip Program ROM Width 14
CPU Family PIC
Number of Programmable I/O 18
Integrated Cache NO
RAM (words) 128
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 0.55mm
Length 4mm
Compliance
RoHS Status ROHS3 Compliant
