S80C188XL20
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
MPU 188 Processor CISC 16-Bit 20MHz 80-Pin QFP
PDF
/
Buying Options
Total Price: USD $24.49
Unit Price: USD $24.4872
≥1 USD $24.4872
≥10 USD $20.09155
≥100 USD $19.4636
≥500 USD $18.8366
≥1000 USD $18.20865
Inventory: 1399
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 14mm
Length 20mm
Height Seated (Max) 3.15mm
Technical
Number of DMA Channels 2
Number of External Interrupts 5
RAM (words) 0
Integrated Cache NO
Format FIXED POINT
External Data Bus Width 8
Low Power Mode YES
Boundary Scan NO
Address Bus Width 20
Bit Size 16
Supply Current-Max 90mA
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Voltage 5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 80
Frequency 20MHz
Terminal Pitch 0.8mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microprocessors
HTS Code 8542.31.00.01
Additional Feature DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 3A991.A.2
Number of Terminations 80
JESD-609 Code e0
Packaging Bulk
Physical
Number of Pins 80
Package / Case PQFP
Mount Surface Mount
