PIC12F1840-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC12 PIC RISC 7KB Flash 3.3V/5V Automotive 8-Pin PDIP Tube
PDF
/
Buying Options
Total Price: USD $1.53
Unit Price: USD $1.5312
≥1 USD $1.5312
≥10 USD $1.4168
≥100 USD $1.2848
Inventory: 558
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.112mm
Length 10.16mm
Height 4.953mm
Technical
Number of PWM Channels 1
Number of External Interrupts 1
Number of Serial I/Os 1
Number of ADC Channels 4
RAM (words) 256
Integrated Cache NO
Format FIXED-POINT
Low Power Mode NO
Boundary Scan NO
EEPROM Size 256 x 8
Core Architecture AVR
Address Bus Width 8b
Number of Timers/Counters 3
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 4x10b; D/A 1x5b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 256 x 8
Nominal Supply Current 34μA
Number of I/O 5
Oscillator Type Internal
Memory Size 4kB
Interface I2C, LIN, SPI, UART, USART
Pin Count 8
Base Part Number PIC12F1840
Frequency 12MHz
Supply Voltage 3V
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 12F
Published 2010
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 7 Weeks
