DSPIC33FJ06GS102AT-E/TL
RoHS
RoHS compliant
RoHS compliantPackage 36-VFTLA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 6KB FLASH 36VTLA
PDF
/
Inventory: 5630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-VFTLA Exposed Pad
Number of Pins 36
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2012
Series Automotive, AEC-Q100, dsPIC? 33F
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 36
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 40MHz
Base Part Number DSPIC33FJ06GS102A
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 6kB
Oscillator Type Internal
Number of I/O 21
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 6KB 2K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 6x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
On Chip Program ROM Width 24
Boundary Scan YES
Low Power Mode NO
Integrated Cache NO
RAM (words) 128
Number of Serial I/Os 1
Number of External Interrupts 3
On Chip Data RAM Width 16
Dimensions
Height Seated (Max) 1mm
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
