DSPIC33EP32GP503-I/TL
RoHS
RoHS compliant
RoHS compliantPackage 36-VFTLA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 36VTLA
PDF
/
Inventory: 6250
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 36-VFTLA Exposed Pad
Surface Mount YES
Number of Pins 36
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2012
Series dsPIC? 33EP
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 36
ECCN Code 3A991.A.2
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 70MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33EP32GP503
Pin Count 36
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 25
RAM Size 2K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 32KB 10.7K x 24
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 8x10b/12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 10922
On Chip Program ROM Width 24
Format FLOATING-POINT
RAM (words) 2048
Dimensions
Height Seated (Max) 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
