ATSAMS70N21A-AN
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 2MB FLASH 100LQFP
PDF
/
Buying Options
Total Price: USD $13.15
Unit Price: USD $13.1472
≥1 USD $13.1472
≥10 USD $11.9592
≥100 USD $10.8328
Inventory: 364
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 1.6mm
Technical
Core Architecture ARM
Number of Timers/Counters 4
DAC Channels YES
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 10x12b; D/A 2x12b
Bit Size 32
Connectivity I2C, IrDA, LINbus, MMC/SD/SDIO, SPI, UART/USART, USB
Program Memory Size 2MB 2M x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.08V~3.6V
RAM Size 384K x 8
Number of I/O 75
Oscillator Type Internal
Memory Size 2MB
Interface I2C, IrDA, LIN, MMC, SD, SDIO, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 1.08V
Supply Voltage-Max (Vsup) 1.32V
Base Part Number ATSAMS70N
Time@Peak Reflow Temperature-Max (s) 40
Frequency 300MHz
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SAM S70
Published 2016
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
