ATSAMS70J21B-ANT

Microchip Technology
RoHS
RoHS RoHS compliant
Package 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 32BIT 2MB FLASH 64LQFP
PDF
/
Buying Options
Total Price: USD $12.68
Unit Price: USD $12.6808
≥1 USD $12.6808
≥10 USD $11.5104
≥100 USD $10.4456
Inventory: 1534
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 10mm
Length 10mm
Height Seated (Max) 1.6mm

Technical

Screening Level TS 16949
On Chip Program ROM Width 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 5x12b; D/A 1x12b
Bit Size 32
Connectivity I2C, IrDA, LINbus, SPI, UART/USART, USB
Program Memory Size 2MB 2M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 20MHz
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.08V~3.6V
RAM Size 384K x 8
Speed 300MHz
Number of I/O 44
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.08V
Supply Voltage-Max (Vsup) 1.32V
JESD-30 Code S-PQFP-G64
Base Part Number ATSAMS70J
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series SAM S70
Published 2018
Packaging Cut Tape (CT)
Operating Temperature -40°C~105°C TA

Physical

Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 7 Weeks
