ATMEGA32A-MN
RoHS
RoHS compliant
RoHS compliantPackage 44-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 44VQFN
PDF
/
Buying Options
Total Price: USD $2.19
Unit Price: USD $2.188039
≥1 USD $2.188039
≥10 USD $2.064182
≥100 USD $1.947349
≥500 USD $1.837118
≥1000 USD $1.73313
Inventory: 1175
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-VFQFN Exposed Pad
Number of Pins 44
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2014
Series AVR? ATmega
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Additional Feature ALSO OPERATES AT 2.7 V MINIMUM SUPPY AT 8 MHZ
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 16MHz
Base Part Number ATMEGA32A
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 32
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 15mA
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
EEPROM Size 1K x 8
Dimensions
Height Seated (Max) 1mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
